Gas Instrumentation

Gas Hoses can be classified into two main groups: low pressure hoses, which include acetylene, oxygen, butane/propane mix, natural gas, and neutral gas; and high pressure hoses, used for gases, such as gas cylinder filling and emptying applications.

Fluoropolymer Hose Assemblies for Gas

High performing fluoropolymers have minimal permeability for low, medium or high pressure gas transfer and form part of our range of gas suitable hose assemblies which includes PTFE lined hose assemblies, PFA and FEP gas tubing. ETFE is available upon request.

Extruded - Small/closer bonded molecules. Diffusion/dispersion rate is much less than PTFE

  • 6130FEP - SS Braided FEP -
  • 6130PFA - SS Braided PFA -
  • 6131TEFZEL - SS Braided Tefzel -
  • 6140
  • 6145
  • 6150 (552 Bar) SS braided or PU cover
  • 6154
  • 6160
  • 6165
Get in Touch

Metallic Hoses for Gas

Flextech’s range of 321 and 316 stainless steel metallic hose assemblies offer suitability for cryogenic applications as well as high temperature and zero* permeability where a fluoropolymer isn't suitable.

Specialist metal alloys such as Monel are also available upon request.

Get in Touch

Gas Hoses & Fittings

When choosing gas hoses, several important factors related to the properties of the gas should be taken into account. These include flammability, explosiveness, pressure and temperature conditions, permeation of gases through the hose wall, electrostatic properties, gas contamination, flow rate, and adherence to safety requirements. It is crucial to comply with relevant regulations and standards while ensuring an adequate safety factor.

Gas Hose Assemblies:

  • Have a wide operating temperature range from -200°C to +600°C
  • Are designed for cylinder charging, breathing apparatus, discharging lines and aerosol charging lines, welding, fuelling with gas (e.g., LPG), medical applications, food-related uses, and cryogenic applications

Other gas hose assemblies from Flextech and use cases include High pressure Gas and Skydrol applications. All of our gas hoses perform well in food, beverage, petrochemical, chemical, medical and pharmaceutical applications and industry environments.

At Flextech, we supply a range of Gas Hose Assemblies depending on use cases:

• The T6140 PTFE Braided Gas Hose Assemblies from Flextech is a high-quality, lightweight gas hose that is inert to virtually all chemicals. This hose is ideally suited for cylinder charging, breathing apparatus, discharging lines and aerosol charging lines.

• The T6145 PTFE Lined High Pressure Gas Hose Assemblies from Flextech is a high-pressure, non-flammable PTFE gas hose which operates a wide temperature range of -60°C to +260°C, ideal for food, beverage and petrochemical environments.

• The T6450 Castellated PTFE Hose Assemblies is a medium wall virgin PTFE gas hose and with its helical convolution, this hose has excellent flexibility, kink and vacuum resistance.

Search Our Product Database

Filter and Find Your Products

Click Here

Some of Flextech's Gas Hoses
